GS301 Bathroom Odor Detector
From
£ 498.60 (exc. VAT)
 Features
- Built-in, highly accurate electrochemical gas detection sensor with more than a 3-year life expectancy
- Built-in multiple sensors including NH3, H2S, temperature and humidity
- Built-in batteries to achieve wireless power supply and decrease the installation cost
- Equipped with a buzzer and an LED indicator to indicate threshold alarms
- Damp-proof coating inside the device to ensure the device works well in various bathroom conditions
- Supports the Milesight D2D protocol to enable ultra-low latency and direct ventilation control without gateways
- Built-in NFC for easy configuration
- Compatible with standard LoRaWAN® gateways and network servers
- Quick and easy management with the Milesight IoT Cloud solution
Available on back-order
The GS301 is a 4-in-1 LoRaWAN® bathroom odour detector for the detection of ammonia (NH3) and hydrogen sulfide (H2S) gas according to electrochemical principles. GS301 is also able to detect temperature and humidity so it can provide full information about the environment of bathrooms.
When the NH3 or H2S gas concentration reaches the preset threshold, the detector will trigger both an LED light alarm and a buzzer to notify people in good time to ventilate the room, which is an important part of a smart bathroom solution.
Apart from local alarms, GS301 can also report the sensor data and alarm messages remotely by the use of LoRaWAN® technology.
Integrating with the Milesight LoRaWAN® gateway and Milesight IoT Cloud solution, users can monitor all the sensor data and control the device remotely and flexibly. Moreover, GS301 supports the Milesight D2D to enable ultra-low latency control without gateways.
Product Specific Documents:
Datasheet
User Manual
Certificates
Useful Links:
Firmware Versions
Payload Decoders
Download Center
Specifications
| Model: | GS301: | ||
| Wireless Transmission: | Technology: | LoRaWAN® , Milesight D2D | |
| Frequency: | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 | ||
| Tx Power: | 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz) | ||
| Sensitivity: | -137dBm | ||
| Mode: | OTAA/ABP Class A | ||
| Ammonia (NH3): | Detection Principle: | Solid Polymer Electrochemical | |
| Range: | 0 ~ 10 ppm | ||
| Accuracy: | ± 5% (-40 – 35°C) | ||
| Resolution: | 0.01 ppm | ||
| Long-term Stability: | < 1 % accuracy drift per month | ||
| Hydrogen Sulfide (H2S): | Detection Principle: | Solid Polymer Electrochemical | |
| Range: | 0 ~ 5 ppm | ||
| Accuracy: | ± 5% (-40 – 35°C) | ||
| Resolution: | 0.01 ppm | ||
| Long-term Stability: | < 1 % accuracy drift per month | ||
| Temperature: | Range: | -40 – 85°C | |
| Accuracy: | ± 0.2°C | ||
| Resolution: | 0.01°C | ||
| Humidity: | Range: | 0 – 100%RH | |
| Accuracy: | ± 2% | ||
| Resolution: | 0.5%RH | ||
| Others: | Button: | 1 Ă— Reset/Reboot Button | |
| LED & Buzzer: | 1 Ă— Status/Alarm Indicator + 1 Ă— Buzzer | ||
| Configuration: | Mobile App via NFC | ||
| Advanced Features: | Milesight D2D Controller | ||
| Physical Characteristics | Power Supply: | 4 x 4000 mAh ER18505 Li-SOCl2 Replaceable Batteries | |
| Sensor Life: | >3 Years | ||
| Battery Life | Around 3 Years (10 min interval) | ||
| Operating Temperature: | -40°C – 55°C | ||
| Relative Humidity: | 0% – 95% (non-condensing) | ||
| Ingress Protection: | IP30 | ||
| Dimensions: | 120 Ă— 85 Ă— 32.5 mm (4.72 Ă— 3.35 Ă— 1.28 in) | ||
| Material & Colour: | PC+ABS (Flame Retardant), White | ||
| Installation: | Wall Mounting | ||
| Approvals: | Regulatory: | CE, FCC,RoHS |
